T8 Tube
Type C

IKIO’s T8 Tube Type C effectively combines the best of both Type A and Type B tubes. It is designed to work with an external driver, separate from the luminaire itself, which allows for greater control over lighting performance and efficiency.

PRODUCT FEATURES

  • Simple and uniform design makes it easier to install and replace existing fixtures, reducing the costs considerably; supported by two-end input configuration.
  • Outfitted with a high-quality external driver, delivering soft and comfortable lighting; no infrared or UV rays.
  • Comes with a dimming option (0-10 V) for enhanced lighting control.
  • Suitable for use in dry and damp locations and in low temperatures.
INQUIRE NOW
Product Details
Efficacy (lm/W) 141lm/W
Power (W) 15W
CCT (K) 3000K, 3500K, 4000K, 4500K, 5000K
CRI 83
Voltage AC 100-277V 50/60 Hz
Beam Angle 160°
Dimming Continuous Dimming to 10% or Below
Operating Temperature -4ºF ~ +122ºF
Housing Aluminum & Plastic
Technical Resources
Product Sheet

T8_Tube_Type_C_PS.pdf

LM79

LM79.zip

Installation Instructions

T8_TUBE_TYPE_C_Installation Instructions.pdf

SKU Details


Power SKU Number Model CCT Diffuser Efficacy Voltage Lumen Output Size Ordering Part Number Qualified Part Number Technical Data Sheet IES File
15W 662187533858 T8 Tube Type C 3000K Clear 140lm/W 100-277V 2100lm 4ft IK-T804-EX0015-DY-30C-J(Clear) IK-T804-EX0015-DY-30C-J Download Download
15W 662187540641 T8 Tube Type C 3500K Clear 141lm/W 100-277V 2115lm 4ft IK-T804-EX0015-DY-35C-J(Clear) IK-T804-EX0015-DY-35C-J Download Download
15W 662187540627 T8 Tube Type C 4000K Clear 141lm/W 100-277V 2115lm 4ft IK-T804-EX0015-DY-40C-J(Clear) IK-T804-EX0015-DY-40C-J Download Download
15W 662187540634 T8 Tube Type C 4500K Clear 141lm/W 100-277V 2115lm 4ft IK-T804-EX0015-DY-45C-J(Clear) IK-T804-EX0015-DY-45C-J Download Download
15W 662187540610 T8 Tube Type C 5000K Clear 141lm/W 100-277V 2115lm 4ft IK-T804-EX0015-DY-50C-J(Clear) IK-T804-EX0015-DY-50C-J Download Download
15W 662187533865 T8 Tube Type C 3000K Frosted 130lm/W 100-277V 1950lm 4ft IK-T804-EX0015-DN-30C-J(Frosted) IK-T804-EX0015-DN-30C-J Download Download
15W 662187533889 T8 Tube Type C 3500K Frosted 131lm/W 100-277V 1965lm 4ft IK-T804-EX0015-DN-35C-J(Frosted) IK-T804-EX0015-DN-35C-J Download Download
15W 662187533872 T8 Tube Type C 4000K Frosted 131lm/W 100-277V 1965lm 4ft IK-T804-EX0015-DN-40C-J(Frosted) IK-T804-EX0015-DN-40C-J Download Download
15W 662187533896 T8 Tube Type C 4500K Frosted 132lm/W 100-277V 1980lm 4ft IK-T804-EX0015-DN-45C-J(Frosted) IK-T804-EX0015-DN-45C-J Download Download
15W 662187533902 T8 Tube Type C 5000K Frosted 132lm/W 100-277V 1980lm 4ft IK-T804-EX0015-DN-50C-J(Frosted) IK-T804-EX0015-DN-50C-J Download Download
