IKIO's T8 Glass Tube–Type B is designed to operate without a ballast, providing a direct replacement for T8 fluorescent lights. Featuring an internal driver and a built-in dimmer, it offers high efficiency, adjustable brightness, and clear illumination. Its corrosion-resistant, durable construction ensures long-lasting performance while reducing energy and maintenance costs. Available in frosted lens, and clear lens options, it suits a range of indoor applications.
- No ballast needed. Can run directly off the main switch without any major reiwiring.
Compatible with single-ended power input.
- Built-in dimmer offers seamless brightness control, providing flexible
and energy-efficient lighting.
- Wide beam angle provides ample coverage; free from flickering, humming, or dark spots.
- A convenient retrofit for traditional tube light, offering energy savings and reduced maintenance costs.
- Exceptional efficacy with high lumen output, ensuring bright, clear, and even illumination.
- Suitable for damp locations and low temperatures.
.png)
| Size | 4' |
| Efficacy (lm/W) | Up to 130lm/W |
| Power (W) | 14W |
| CCT (K) | 3000K, 3500K, 4000K, 4100K, 4500K, 5000K, 5700K, 6500K |
| CRI | 83 |
| Voltage | AC 120-277V 50/60 Hz |
| Beam Angle | 198° |
| Dimming | Built-In, 0-10V Dimming Driver, Dims to 10% |
| Operating Temperature | -4ºF ~ +113ºF |
| Housing | Glass |
| Power | SKU Number | Model | CCT | Diffuser | Efficacy | Voltage | Lumen Output (lm) |
Size | Ordering Part Number | Qualified Part Number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 14.5W | 662187510583 | T8 Glass Tube (Built-in Dimmer) | 3000K | Frosted | 124.1lm/W | 120-277V | 1800lm | 4ft | IK-GT804-DIM-14W-30KB-SF | IK-GT804-DIM-14W-30KB-SF | Download | Download |
| 14.5W | 662187510590 | T8 Glass Tube (Built-in Dimmer) | 3500K | Frosted | 127.6lm/W | 120-277V | 1850lm | 4ft | IK-GT804-DIM-14W-35KB-SF | IK-GT804-DIM-14W-35KB-SF | Download | Download |
| 14.5W | 662187510606 | T8 Glass Tube (Built-in Dimmer) | 4100K | Frosted | 131lm/W | 120-277V | 1900lm | 4ft | IK-GT804-DIM-14W-41KB-SF | IK-GT804-DIM-14W-41KB-SF | Download | Download |
| 14.5W | 662187508900 | T8 Glass Tube (Built-in Dimmer) | 4000K | Frosted | 131lm/W | 120-277V | 1900lm | 4ft | IK-GT804-DIM-14W-40KB-SF | IK-GT804-DIM-14W-40KB-SF | Download | Download |
| 14.5W | 662187510613 | T8 Glass Tube (Built-in Dimmer) | 4500K | Frosted | 131lm/W | 120-277V | 1900lm | 4ft | IK-GT804-DIM-14W-45KB-SF | IK-GT804-DIM-14W-45KB-SF | Download | Download |
| 14.5W | 662187510620 | T8 Glass Tube (Built-in Dimmer) | 5000K | Frosted | 134.5lm/W | 120-277V | 1950lm | 4ft | IK-GT804-DIM-14W-50KB-SF | IK-GT804-DIM-14W-50KB-SF | Download | Download |
| 14.5W | 662187510637 | T8 Glass Tube (Built-in Dimmer) | 5700K | Frosted | 134.5lm/W | 120-277V | 1950lm | 4ft | IK-GT804-DIM-14W-57KB-SF | IK-GT804-DIM-14W-57KB-SF | Download | Download |
| 14.5W | 662187510644 | T8 Glass Tube (Built-in Dimmer) | 6500K | Frosted | 134.5lm/W | 120-277V | 1950lm | 4ft | IK-GT804-DIM-14W-65KB-SF | IK-GT804-DIM-14W-65KB-SF | Download | Download |
