T5 Tube
Type B

IKIO's T5 Tube – Type B is engineered to be a seamless replacement for your existing T5 fluorescent lights, as it comes with a ballast bypass design.

PRODUCT FEATURES

  • Can run directly off the main switch without any major rewiring.
  • Designed to have that perfect uniform visual appearance to make an easy replacement for traditional lights.
  • Delivers exceptional efficacy and light output with a wide beam angle; there is no flickering, humming, or dark spots.
  • An in-built driver results in enhanced efficiency and decreased energy and maintenance costs.
  • Ideal for operation in dry and damp areas and in low temperatures.
INQUIRE NOW
Product Details
Efficacy (lm/W) 169lm/W
Power (W) 9W, 15W, 24W
CCT (K) 4000K , 5000K
CRI 83
Voltage 100-277V
Beam Angle 168°
Dimming Continuous Dimming to 10% or Below
Operating Temperature -4°F ~ +104°F
Housing Aluminum Shell
Technical Resources
Product Sheet

T5_Tube_Type_B_PS.pdf

LM79 Reports

LM79_IK-T504-0015-XXB.pdf

Installation Instructions

T5_Tube_Type_B_Installation Instructions.pdf

SKU Details

Power SKU Number Model CCT Diffuser Efficacy Voltage Lumen Output (lm) Size Ordering Part Number Qualified Part Number Technical Data Sheet IES File
15.7W 662187485348 T5 Tube Type B 4000K Clear 160.71lm/W 100-277V 2520lm 4ft IK-T504-0015-DY-4000B (Clear) IK-T504-0015-DY-4000B Download Download
15.7W 662187486390 T5 Tube Type B 5000K Clear 165.37lm/W 100-277V 2593lm 4ft IK-T504-0015-DY-5000B (Clear) IK-T504-0015-DY-5000B Download Download
23.2W 662187485355 T5 Tube Type B 4000K Frosted 134.85lm/W 100-277V 3146lm 4ft IK-T504-0024-DY-4000B(Fr) IK-T504-0024-DY-4000B Download Download
23.2W 662187487069 T5 Tube Type B 5000K Frosted 137.93lm/W 100-277V 3218lm 4ft IK-T504-0024-DY-5000B(Fr) IK-T504-0024-DY-5000B Download Download
9W 662187488103 T5 Tube Type B 5000K Frosted 160lm/W 100-277V 1440lm 2ft IK-T502-0009-DY-50K (Fr) Not Qualified Yet Download Download
9W 662187488097 T5 Tube Type B 4000K Frosted 160lm/W 100-277V 1440lm 2ft IK-T502-0009-DY-40K (Fr) Not Qualified Yet Download Download
