Orwin Downlight
CCT & Power Selectable

Create the desired lighting effect in your stores with IKIO’s Orwin, a circular LED ambient light made of aluminum die cast with high quality powder coated luminaire housing and optimum heat sink. These properties of the luminaire contribute to its effective functioning for a longer time period. Moreover, available in multiple wattages, color temperatures, finishes, and beam angles, this luminaire offers greater flexibility in its application.

PRODUCT FEATURES

• Even light distribution without halo and shadows.
• Suitable for wet locations.
• Excellent heat dissipation with flicker-free light.
• Incorporates intelligent control technology.

INQUIRE NOW
Product Details
Efficacy (lm/W)

6" - Up to 90.24 lm/W

8" - Up to 95.64 lm/W

10" - Up to 93.83 lm/W
Power (W)

6" -  12 W-17 W-22 W

8" -  17 W-24 W - 30 W

10" - 22 W - 30 W - 38 W
CCT (K) 2700 K-3000 K-3500 K-4000 K-5000 K
CRI >90
Voltage AC 120-277 V 50/60 Hz
Beam Angle 100°
Dimming 0-10 V
Operating Temperature -14° F to +122° F
Technical Resources
Product Sheet

Orwin_DL_PS.pdf

Installation Instructions

Orwin_DL_Installation_Instructions.pdf

LM80 Report

LM80_Orwin_DL.PDF

SKU Details
Power SKU Number Efficacy CCT Voltage Lumen Output Distribution/ Beam angle Finish Size Diffuser Ordering Part Number EnergyStar Part Number Technical Data Sheet IES File
12 W-17 W-22 W 662187477466 90.24 lm/W-87.50 lm/W-84.68 lm/W 2700 K-3000 K-3500 K-4000 K-5000 K 120-277 V 1045 lm-1484 lm-1790.2 lm 100° White 6" Frosted IK-DLR6L-121722-CCT IK-DLR6L-121722-CCT Download Download
17 W-24 W-30 W 662187477459 95 lm/W-90 lm/W-95.64 lm/W 3000 K-4000 K-5000 K 120-277 V 1615 lm-2160 lm- 2587 lm 100° White 8" Frosted IK-DLR8L-172430-CCT IK-DLR8L-172430-CCT Download Download
22 W-30 W-38 W 662187478753 93.83 lm/W-91.50 lm/W-89.11 lm/W 2700 K-3000 K-3500 K-4000 K-5000 K 120-277 V 2006 lm-2583 lm-3199.0 lm 100° White 10" Frosted IK-DLR10L-223038-CCT IK-DLR10L-223038-CCT Download Download
