Delphi
Linear Low Bay
IKIO’s Delphi Linear Low Bay — an energy efficient replacement for traditional fluorescent tubes — comes with excellent CCT & Power selectable capabilities. It allows customers to select different CCTs & wattages, thereby offering greater flexibility when it comes to application areas. Moreover, the luminaire’s superior design helps in rendering smooth and evenly distributed light output with no dark areas.
PRODUCT FEATURES
• Incorporates advanced technology - CCT & power selectable capabilities for greater light control.
• Quick and hassle-free installation.
• Energy saving technology - saves greater energy over the traditional lighting fixtures.
• High performing luminaire - smooth and evenly distributed light output with no dark areas.
• Flexibility of application - suitable for multiple applications because of its low profile and CCT & Power selectable feature.
Product Details
| Efficacy (lm/W) | 140 lm/W |
| Power (W) |
(2ft) 15 W-18 W- 22 W-25 W (4ft) 30 W-36 W-40 W-50 W (8ft) 60 W-68 W-72 W-80 W |
| CCT (K) | 3500 K - 4000 K - 5000 K |
| CRI | 80+ |
| Voltage | AC 100-277 V 50/60 Hz |
| Beam Angle | 120° |
| Dimming | Continuous Dimming to 10% or below (0-10V) |
| Operating Temperature | -14° F to +122° F |
| IP Rating | IP40 |
| Housing | Aluminum |
Technical Resources
Product Sheet
SKU Details
|
Power |
SKU Number |
CCT |
Voltage |
Lumen Output (lm) |
Size |
Qualified part number |
Ordering part number |
Technical Data Sheet |
IES File |
|---|---|---|---|---|---|---|---|---|---|
|
15 W-18 W-22 W-25 W |
662187528298 |
3500 K-4000 K-5000 K |
120-347 V |
1905 lm-2286 lm-2794 lm-3175 lm |
2' |
IK-SL02R (15/18/22/25)W-?35/40/50?K[SV,LV]-[S?][C,P] |
IK-SL02R-15/18/22/25W-35/40/50KLV-C |
||
|
30 W-36 W-40 W-50 W |
662187528304 |
3500 K-4000 K-5000 K |
120-347 V |
3810 lm-4572 lm-5080 lm-6350 lm |
4' |
IK-SL04R (30/36/40/50)W-?35/40/50?K[SV,LV]-[S?][C,P] |
IK-SL04R-30/36/40/50W-35/40/50KLV-C |
||
|
60 W-68 W-72 W-80 W |
662187528328 |
3500 K-4000 K-5000 K |
120-347 V |
8400 lm-9520 lm-10800 lm-10200 lm |
8' |
IK-SL08R (60/68/72/80)W-?35/40/50?K[SV,LV]-[S?][C,P] |
IK-SL08R-60/68/72/80W-35/40/50KLV-C |
