Striza
Magnetic Strip Kit

IKIO Striza Magnetic Strip Kit is an economy-level LED retrofit for 2’x 2’ & 2′ x 4′ recessed and surface mounted troffers or any linear fluorescent fixture. These kits are easy to install using simple hand tools with minimum modification to the existing housing.

PRODUCT FEATURES

  • Up to 40% energy saving over conventional fluorescent fixtures.
  • Wide aluminum carrier angles which provides improved heat sinking and optic diffusion capability.
  • Easy to install with magnetic retrofit technology.



    Limited Availability: Products Offered Until Stock Lasts.
INQUIRE NOW
Product Details
Efficacy (lm/W) 110 lm/W
Power (W) 20 W
CCT (K) 4000 K, 5000 K
CRI 80+
Voltage AC 100-277 V 50/60 Hz (Driver Required)
Beam Angle 120°
Dimming 0-10 V, Range 10% - 100%
Operating Temperature -04° F to +122° F
IP Rating IP40
Housing Aluminum and Metal sheet
Technical Resources
Product Sheet

Striza_MSL_PS.pdf

LM79 Reports

LM79_Striza.zip

Installation Instructions

Striza_MSL_Installation_Instructions.pdf

SKU Details

Power SKU Number CCT Voltage Lumen Output Beam Angle Size Diffuser Strip Qualified part number Ordering part number Technical Data Sheet IES File
40 W (20 W x 2 Strips) 662187495095 4000 K AC 100-277 V 4400 lm (2200 lm x 2 Strips) 120° 4 ft Frosted 2 Not Qualified Yet IK-MS04-002022-2-DY-40-J Download Download
40 W (20 W x 2 Strips) 662187495149 5000 K AC 100-277 V 4720 lm (2360 lm x 2 Strips) 120° 4 ft Frosted 2 Not Qualified Yet IK-MS04-002022-2-DY-50-J Download Download
