Delphi
Retrofit Troffers 2'x2'

IKIO’s DLC rated Retrofit Troffer is now available with CCT & Power selectable option. This new feature will allow users to conveniently switch CCTs and Wattages to serve various application areas. Delphi Retrofit Troffer is available in two sizes (2' x 2', 2' x 4'), each with a variety of highly efficient lumen packages to suit multiple lighting needs.

PRODUCT FEATURES

• Exceptional efficacy (130 lm/W).
• State-of-the-art technology - incorporates CCT & Power selectable options.
• Suitable for damp locations.
• Energy saving technology - saves greater energy over traditional lighting fixtures.
• Long lasting, high-gloss finish for metal surfaces.
• Highly durable - baked with powder paint for durability and better aesthetics.
• Retrofit option available - can be used with existing fixtures for retrofit application.

Product Details
Efficacy (lm/W) 140 lm/W
Power (W)

(2' x 2') 20 W-25 W-30 W

CCT (K) 3500 K - 4000 K- 5000 K
CRI 80+
Voltage AC 100-277 V 50/60 Hz
Beam Angle 120°
Dimming Continuous Dimming to 10% or below (0-10V)
Operating Temperature -14° F to +122° F
IP Rating IP40
Housing Aluminum
Technical Resources
Product Sheet
SKU Details
Power SKU Number CCT Voltage Lumen Output (lm) Size Qualified Product Code Technical Data Sheet IES File
20 W-25 W-30 W  662187529325 3000 K-4000 K-5000 K 120-277 V 2600 lm-3250 lm-3900 lm 2x2 IK-RT22E-202530-CCT-D Download On Request
