Locus
Area Luminaire

IKIO Locus Area Luminaire combines the duo of architectural form and versatility to make it an excellent choice for new construction or for retrofit applications. It is offered in a variety of wattages allowing for maximum flexibility in all types of applications. The high output LEDs and custom engineered optics provide excellent uniformity and efficiency. It is designed to replace the existing HID fixtures up to 1000 W.

PRODUCT FEATURES

  • Exceptional efficacy (140 lm/W).
  • 100,000 hours of lifetime.
  • Excellent efficacy with an improved light output.
  • Sleek and modern aesthetics combined with a rugged construction.
  • In-built surge protection mechanism.
  • Superior thermal dissipation from an integrated heat sink.
  • Dimming option available, mode – Voltage 1~10V DC, PWM signal 10V), Resistance 10K/N~100K/N Ohms).
Product Details
Efficacy (lm/W) 140 lm/W
Power (W) 100 W, 150 W, 200 W, 240 W, 300 W
CCT (K) 3000 K, 3500 K, 4000 K, 4500 K, 5000 K, 5700 K
CRI 80+
Voltage AC 100-277 V 50/60 Hz
Distribution Type 3-M,Type 2-M,Type 3-S,Type 4-S,Type 5-M,90x120
Dimming Yes
Operating Temperature -40° F to +120° F
IP Rating IP66
Housing Aluminum + Polycarbonate (Optics)
Technical Resources
Product Sheet
LM79 Reports
Installation Instructions
SKU Details
Power SKU Number CCT Voltage Lumen Output Distribution/ Beam angle Finish Qualified Product Code Technical Data Sheet IES File
100 W 662187461847 4000 K AC 100-277 V 14000 lm Type 3M Bronze IK-SBSL1-0100-40-DY-RLV01 Download On Request
100 W 662187461854 4000 K AC 100-277 V 14000 lm Type 5M Bronze IK-SBSL1-0100-40-DY-RLV01 Download On Request
100 W 662187461861 4000 K AC 100-277 V 14000 lm Type 5M White Not Qualified Yet Download On Request
100 W 662187461878 4000 K AC 100-277 V 14000 lm Type 3M White Not Qualified Yet Download On Request
100 W 662187461885 5000 K AC 100-277 V 14000 lm Type 5M White Not Qualified Yet Download Download
100 W 662187549804 5000 K AC 100-277 V 14000 lm Type 3M Bronze Not Qualified Yet Download Download
100 W 662187461892 5000 K AC 100-277 V 14000 lm Type 5M Bronze Not Qualified Yet Download Download
100 W 662187551944 5000 K AC 100-277 V 14000 lm Type 3M White Not Qualified Yet Download Download
150 W 662187461908 4000 K AC 100-277 V 21000 lm Type 3M White IK-SBSL1-0150-40-DY-RLV01 Download On Request
150 W 662187549460 4000 K AC 100-277 V 21000 lm Type 3M Bronze Not Qualified Yet Download On Request
150 W 662187461915 4000 K AC 100-277 V 21000 lm Type 5M White Not Qualified Yet Download On Request
150 W 662187461922 4000 K AC 100-277 V 21000 lm Type 5M Bronze Not Qualified Yet Download On Request
150 W 662187549811 5000 K AC 100-277 V 21000 lm Type 3M Bronze IK-SBSL1-0150-50-DY-RLV01 Download Download
150 W 662187551968 5000 K AC 100-277 V 21000 lm Type 3M White Not Qualified Yet Download Download
150 W 662187547428 5000 K AC 100-277 V 21000 lm Type 5M White Not Qualified Yet Download Download
150 W 662187475172 5000 K AC 100-277 V 21000 lm Type 5M Bronze Not Qualified Yet Download Download
200 W 662187461953 4000 K AC 100-277 V 28000 lm Type 3M White IK-SBSL1-0200-40-DY-RLV02 Download On Request
200 W 662187461960 4000 K AC 100-277 V 28000 lm Type 3M Bronze Not Qualified Yet Download On Request
200 W 662187461984 4000 K AC 100-277 V 28000 lm Type 5M White Not Qualified Yet Download On Request
200 W 662187462011 4000 K AC 100-277 V 28000 lm Type 5M Bronze Not Qualified Yet Download On Request
200 W 662187549828 5000 K AC 100-277 V 28000 lm Type 3M Bronze IK-SBSL1-0200-50-DY-RLV02 Download Download
200 W 662187462042 5000 K AC 100-277 V 28000 lm Type 5M White Not Qualified Yet Download Download
200 W 662187462035 5000 K AC 100-277 V 28000 lm Type 3M White Not Qualified Yet Download Download
200 W 662187462059 5000 K AC 100-277 V 28000 lm Type 5M Bronze Not Qualified Yet Download Download
240 W 662187548579 5000 K AC 100-277 V 33600 lm Type 3M White IK-SBSL1-0240-50-DY-RLV02 Download Download
240 W 662187548012 5000 K AC 100-277 V 33600 lm Type 3M Bronze Not Qualified Yet Download Download
240 W 662187462073 4000 K AC 100-277 V 33600 lm Type 5M White IK-SBSL1-0240-40-DY-RLV02 Download On Request
240 W 662187462080 4000 K AC 100-277 V 33600 lm Type 5M Bronze Not Qualified Yet Download On Request
240 W 662187462097 4000 K AC 100-277 V 33600 lm Type 3M White Not Qualified Yet Download On Request
240 W 662187548562 5000 K AC 100-277 V 33600 lm Type 5M White Not Qualified Yet Download Download
240 W 662187462110 4000 K AC 100-277 V 33600 lm Type 3M Bronze Not Qualified Yet Download On Request
240 W 662187462127 5000 K AC 100-277 V 33600 lm Type 5M Bronze Not Qualified Yet Download Download
300 W 662187462134 5000 K AC 100-277 V 42000 lm Type 3M White IK-SBSL1-0300-50-DY-RLV02 Download Download
300 W 662187549835 5000 K AC 100-277 V 42000 lm Type 3M Bronze Not Qualified Yet Download Download
300 W 662187462158 4000 K AC 100-277 V 42000 lm Type 5M White IK-SBSL1-0300-40-DY-RLV02 Download On Request
300 W 662187462165 4000 K AC 100-277 V 42000 lm Type 5M Bronze Not Qualified Yet Download On Request
300 W 662187462172 4000 K AC 100-277 V 42000 lm Type 3M White Not Qualified Yet Download On Request
300 W 662187547404 5000 K AC 100-277 V 42000 lm Type 5M White Not Qualified Yet Download Download
300 W 662187462196 4000 K AC 100-277 V 42000 lm Type 3M Bronze Not Qualified Yet Download On Request
300 W 662187462202 5000 K AC 100-277 V 42000 lm Type 5M Bronze Not Qualified Yet Download Download
100 W 662187549538 5000 K AC 240-480 V 14000 lm Type 3M Bronze Not Qualified Yet Download Download
100 W 662187549552 5000 K AC 240-480 V 14000 lm Type 3M White Not Qualified Yet Download Download
150 W 662187549569 5000 K AC 240-480 V 21000 lm Type 3M Bronze Not Qualified Yet Download Download
150 W 662187549576 5000 K AC 240-480 V 21000 lm Type 3M White Not Qualified Yet Download Download
200 W 662187462219 5000 K AC 240-480 V 28000 lm Type 3M Bronze Not Qualified Yet Download Download
200 W 662187462226 5000 K AC 240-480 V 28000 lm Type 3M White Not Qualified Yet Download Download
240 W 662187552002 5000 K AC 240-480 V 33600 lm Type 3M Bronze Not Qualified Yet Download Download
240 W 662187462189 5000 K AC 240-480 V 33600 lm Type 3M White Not Qualified Yet Download Download
300 W 662187549620 5000 K AC 240-480 V 42000 lm Type 3M Bronze Not Qualified Yet Download Download
300 W 662187549644 5000 K AC 240-480 V 42000 lm Type 3M White Not Qualified Yet Download Download
100 W 662187462233 5000 K AC 240-480 V 14000 lm Type 5M Bronze Not Qualified Yet Download Download
100 W 662187462240 5000 K AC 240-480 V 14000 lm Type 5M White Not Qualified Yet Download Download
150 W 662187462257 5000 K AC 240-480 V 21000 lm Type 5M Bronze Not Qualified Yet Download Download
150 W 662187462264 5000 K AC 240-480 V 21000 lm Type 5M White Not Qualified Yet Download Download
200 W 662187462271 5000 K AC 240-480 V 28000 lm Type 5M Bronze Not Qualified Yet Download Download
200 W 662187462288 5000 K AC 240-480 V 28000 lm Type 5M White Not Qualified Yet Download Download
240 W 662187462295 5000 K AC 240-480 V 33600 lm Type 5M Bronze Not Qualified Yet Download Download
240 W 662187462301 5000 K AC 240-480 V 33600 lm Type 5M White Not Qualified Yet Download Download
300 W 662187462318 5000 K AC 240-480 V 42000 lm Type 5M Bronze Not Qualified Yet Download Download
300 W 662187462325 5000 K AC 240-480 V 42000 lm Type 5M White Not Qualified Yet Download Download
