Rodella
UFO High Bay
The IKIO Rodella UFO High Bay provides multiple lumen packages and distributions. This fixture offers the necessary optical freedom and flexibility to meet the needs of a wide variety of lighting applications. It is a direct replacement of traditional HID fixtures.
PRODUCT FEATURES
- Smooth and uniform light output with no flickering or humming.
- 100,000 hours of lifetime.
- Superior heat dissipation capability due to its thick aluminum heat sink.
- Elegant and compact design.
- Savings of upto 75% over conventional fluorescent fixtures.
- Resistant to vibration and water.
- Ring Mount included for chain or hook installation.
- Moisture and dust resistant.
- Dimming option available, mode – Voltage 1~10V DC , PWM signal (10V), Resistance 10K/N~100K/N Ohms).
| Limited Availability: Products Offered Until Stock Lasts. |
Product Details
| Efficacy (lm/W) | 140 lm/W |
| Power (W) | 150 W, 240 W |
| CCT (K) | 3500 K, 4000 K, 5000 K |
| CRI | 70+ |
| Voltage | AC 100-277 V 50/60 Hz |
| Beam Angle | 120° |
| Dimming | 0-10 V, Range 10%-100% |
| Operating Temperature | -10° F to +120° F |
| IP Rating | IP65 |
| Housing | Aluminum |
Technical Resources
Product Sheet
LM79 Reports
Installation Instructions
SKU Details
| Power | SKU Number | CCT | Voltage | Lumen Output | Qualified part number | Ordering part number | Technical Data Sheet | IES File |
|---|---|---|---|---|---|---|---|---|
| 147.8 W | 662187549446 | 3500 K | AC 100-277 V | 20848.9 lm | Not Qualified Yet | IK-HBP2-0150-35-DY-RLV01 | Download | Download |
| 147.8 W | 662187549453 | 4000 K | AC 100-277 V | 20848.9 lm | Not Qualified Yet | IK-HBP2-0150-40-DY-RLV01 | Download | Download |
| 235.1 W | 662187537245 | 5000 K | AC 100-277 V | 33599.5 lm | Not Qualified Yet | IK-HBP2-0240-50-DY-RLV02 | Download | Download |
