Luminix
Stadium Flood Light

IKIO’s Luminix Stadium Flood Light is a next-gen, power-selectable lighting solution engineered for precise, high-performance illumination. Its robust die-cast aluminum construction ensures durability in harsh environments, while an advanced heat sink maximizes thermal dissipation for long-term reliability. With a compact 2.7ft² EPA for added stability and superior optics delivering exceptional lumen output, Luminix is a more affordable choice within IKIO’s stadium lighting range—ideal for smaller fields and retrofit projects that demand uncompromised performance.

PRODUCT FEATURES

  • Power selectability provides on-site lumen adjustment to suit varying athletic lighting requirements, from practice fields to tennis courts and other sports arenas.
  • High lumen performance combined with exceptional efficacy supports energy-efficient illumination across demanding applications.
  • Streamlined low EPA profile minimizes wind load, reducing structural stress and supporting long-term fixture stability.
  • Optional visor and laser accessory (sold separately) available for enhanced glare control and precise fixture aiming.
  • DMX control compatibility supports advanced features including color tuning, zoning, scheduling, and remote system operation.
  • Equipped with 0–10V dimming for precise light level control and integrated surge protection to ensure stable performance in fluctuating electrical conditions.
  • IP65-rated construction supports outdoor durability, making it ideal for wet locations and harsh environmental conditions.
 Made to Order



Product Details

Efficacy (lm/W)

152.99lm/W

Power Selectable (W)

500W-600W-700W-800W

Color Temperature (CCT)

3000K / 4000K / 5000K / 5700K

CRI

72

Voltage

100 - 270V / 277 - 480V

Beam Angle

35˚

Dimming

Continuous Dimming to 10% or below

Operating Temperature

-40°F + 113°F

IP Rating

IP65

Housing

Die-cast aluminum

EPA

2.7ft²

Wind Rating

1.2 mph

BUG Rating

B5-U0-G3

Technical Resources
Product Sheet
Installation Instructions
SKU Details
Max Power SKU Number Efficacy CCT Voltage Lumen Output Beam angle Ordering Part Number Qualified Product Code Technical Data Sheet IES File
806.7W 662187511924 149.99lm/W 4000K 120-277V 74995lm-89994lm-104993lm-120993lm 35° IK-SP11-800/700/600/500W-E1PD2MV-40K-BL-SH-20SP-FM IK-SP11-800/700/600/500W-E1PD2MV-[BR, WH, BL][10SP, 20SP or blank][ “AM”, “TM”or “FM”]40 Download Download
799.7W 662187511948 151.77lm/W 4000K 277-480V 75885lm-91062lm-106239lm-121365lm 35° IK-SP11-800/700/600/500W-E1PD2HV-40K-BL-SH-20SP-FM IK-SP11-800/700/600/500W-E1PD2HV-[BR, WH, BL][10SP,20SP or blank][ “AM”, “TM”or “FM”]40 Download On Request
807W 662187541631 150.25lm/W 4500K 120-277V 75125lm-90150lm-105175lm-121245lm 35° IK-SP11-800/700/600/500W-E1PD2MV-45K-BL-SH-20SP-FM IK-SP11-800/700/600/500W-E1PD2MV-[BR, WH, BL][10SP,20SP or blank][ “AM”, “TM”or “FM”]45 Download On Request
800W 662187541648 152.15lm/W 4500K 277-480V 76075lm-91290lm-106505lm-121724lm 35° IK-SP11-800/700/600/500W-E1PD2HV-45K-BL-SH-20SP-FM IK-SP11-800/700/600/500W-E1PD2HV-[BR, WH, BL][10SP,20SP or blank][ “AM”, “TM”or “FM”]45 Download On Request
807W 662187509266 150.56lm/W 5000K 120-277V 75280lm-90336lm-105392lm-121497lm 35° IK-SP11-800/700/600/500W-E1PD2MV-50K-BL-SH-20SP-FM IK-SP11-800/700/600/500W-E1PD2MV-[BR, WH, BL][10SP,20SP or blank][10SP, 20SP or blank]50 Download On Request
800W 662187487922 152.6lm/W 5000K 277-480V 76300lm-91560lm-106820lm-122083lm 35° IK-SP11-800/700/600/500W-E1PD2HV-50K-BL-SH-20SP-FM IK-SP11-800/700/600/500W-E1PD2HV-[BR, WH, BL][10SP,20SP or blank][10SP, 20SP or blank]50 Download On Request
807.3W 662187511931 150.82lm/W 5700K 120-277V 75410lm-90492lm-105574lm-121749lm 35° IK-SP11-800/700/600/500W-E1PD2MV-57K-BL-SH-20SP-FM IK-SP11-800/700/600/500W-E1PD2MV-[BR, WH, BL][10SP,20SP or blank][ “AM”, “TM”or “FM”]57 Download On Request
800.3W 662187511955 152.99lm/W 5700K 277-480V 76495lm-91794lm-107093lm-122442lm 35° IK-SP11-800/700/600/500W-E1PD2HV-57K-BL-SH-20SP-FM IK-SP11-800/700/600/500W-E1PD2HV-[BR, WH, BL][10SP,20SP or blank][ “AM”, “TM”or “FM”]57 Download Download
